Border Defense Dual Fov Night Vision Cooled Thermal Camera
Product Features35/180 Dual FOV lens,Search detection in wide field of view mode, narrow field goal of pattern recognitionSpecial Image processing , flat image with no noise, pseudo color and 2 formats: hot black/hot whiteLow power consumption,Start quicklyRS485,Analog video outputHigh aluminum allo......
Send Inquiry
Product Description
Product Features
3 Our Services
(1) We generally offer one year warranty. Extended warranty is also available.
(2) Life-long technical support. Professional technical team and salesperson help you with troubleshooting procedures any time when needed.
(3) We accept OEM.
(4) We offer customized product.
4 Company Introduction
China Sheenrun Optics & Electronics Co., Ltd, which was founded in 2004, is a leading night vision equipment and rugged information equipment supplier, as well as a relying construction company of Shandong Province Academician Workstation and Night Vision Surveillance Engineering Technology Research Center. Sheenrun adheres to independent innovation, developed the world's first laser night vision camera and the first uncooled continuous zoom infrared thermal imaging camera with independent intellectual property rights, its synchronous zoom laser night vision technology and continuous zoom thermal imaging technology have reached international advanced standard level, possess the world's largest market share in laser night vision market.
- 35/180 Dual FOV lens,Search detection in wide field of view mode, narrow field goal of pattern recognition
- Special Image processing , flat image with no noise, pseudo color and 2 formats: hot black/hot white
- Low power consumption,Start quickly
- RS485,Analog video output
- High aluminum alloy shell: with nitrogen inside; can work under harsh environment
| Distance | Target | Human(1.8m×0.5m) | vehicle(2.3m×2.3m) |
| Detect | 4000m | 10000m | |
| Recognize | 1000m | 2500m | |
| identify | 500m | 1250m | |
| Lens | Focal length | 35/180mm | |
| FOV | 3.1°×2.4°/15.6°×12.5° | ||
| IFOV | 0.167/0.857mrad | ||
| Lens Control | Electronic | ||
| Sensor | Type | Cooled sensor | |
| Resolution | 320×256 | ||
| Spectrum | 3.7~4.8μm | ||
| NETD | ≤25mK | ||
| Frequency | 25Hz | ||
| FFC | Auto/manual/scene | ||
| Image | DDE/pseudo color | ||
| Video output | PAL/NTSC | ||
| Starting tiem | ≤7.5 second(under 25ºC) | ||
| Interface | Power | DC24V | |
| Other | RS485,BNC | ||
| Environmental indicators | Operation Temperature | -30ºC~+55ºC | |
| Storage Temperature | -40ºC~+70ºC | ||
| Protection grade | IP66 | ||
| Vibration | 10~55Hz,0.75mm | ||
| Anti-impact | 150m/s2,11ms | ||
| Salt Fog Proof | Continuously spraying 48 hours under PH 6.5~7.2 | ||
| Power | Whole power | DC24V | |
| Power consumption | ≤15W@25ºC, normal value | ||
| ≤30W@25ºC, top value | |||
