CCTV Security 5MP IP Network Bullet Camera
Features 1/3" UHD CMOS sensor Max. 5MP resolution 2592 x 1944 Low illumination 0.1Lux Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT D-WDR, Motion Detection, Privacy Mask, Mirror, Flip RTSP and Onvif 2.6 compatible H.265/H.264 dual-stream media server Easy-to-use P2P Cloud service Multi web browser, P......
Send Inquiry
Product Description
Features
• 1/3" UHD CMOS sensor
• Max. 5MP resolution 2592 x 1944
• Low illumination 0.1Lux
• Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
• D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
• RTSP and Onvif 2.6 compatible
• H.265/H.264 dual-stream media server
• Easy-to-use P2P Cloud service
• Multi web browser, PC Client, mobile APP remote access
• Optional customization Lens/Audio/POE, etc.
• Waterproof level IP66
• 12PCS SMD IR Leds, IR distance 15-20 meters
• HD Fixed 3.6mm Lens
Specification
• 1/3" UHD CMOS sensor
• Max. 5MP resolution 2592 x 1944
• Low illumination 0.1Lux
• Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
• D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
• RTSP and Onvif 2.6 compatible
• H.265/H.264 dual-stream media server
• Easy-to-use P2P Cloud service
• Multi web browser, PC Client, mobile APP remote access
• Optional customization Lens/Audio/POE, etc.
• Waterproof level IP66
• 12PCS SMD IR Leds, IR distance 15-20 meters
• HD Fixed 3.6mm Lens
Specification
| Model | BA-NW12A50-2 |
| Camera | |
| Image Sensor | 1/3" CMOS |
| Effective Pixels | 5 megapixels |
| Electronic Shutter | AUTO |
| Min. Illumination | [email protected](AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto |
| AGC/BLC / HLC | Support |
| DNR | 2D/3D DNR |
| Other | Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip |
| Encode | |
| Video Standard | H.264/H.265 |
| Video Resolution | Main stream: 15fps@5MP(2592x1944),20fps@4MP(2592x1520),30fps@3MP/1080P/720P |
| Sub Stream: VGA(640x480)/360P/QVGA@25fps, etc. | |
| Video Bitrates | 32Kbps - 8Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a/AAC |
| IR Led | |
| IR Led | 12pcs SMD Array IR Leds |
| IR Distance | 15-20M |
| Lens | |
| Focal length | HD Fixed 3.6mm Lens |
| Optional Function | |
| Poe, Audio, etc. | |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
| P2P | Yes |
| Web | IE , Firefox esr |
| Media | CMS, Android, IOS |
| ONVIF | 2.6 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, POE Optional |
| Power Supply | 12 VDC ± 10% |
| Power Consumption | < 5 W |
| Operating Temp. | -20ºC-(+60)ºC, 10%-90%RH |
