CCTV Security Surveillance Analog HD 5MP Ahd Bullet Camera
Feature: AHD output 1/2.5'' 5.0MP CMOS Resolution: 2592 x 1944 , 5.0 Megapixels Minimum illumination:0. Lux/F1.2(0Lux IR ON) IR Distance: 15-30M IR Cut function, Day@night Surveillance Non coding compression, High Efficiency, without delay real-time transmission ......
Send Inquiry
Product Description
Feature:
• AHD output
• 1/2.5'' 5.0MP CMOS
• Resolution: 2592 x 1944 , 5.0 Megapixels
• Minimum illumination:0. Lux/F1.2(0Lux IR ON)
• IR Distance: 15-30M
• IR Cut function, Day@night Surveillance
• Non coding compression, High Efficiency, without delay real-time transmission
• Up to 500 meters lossless transmission with 75-3 coax
Specification:
• AHD output
• 1/2.5'' 5.0MP CMOS
• Resolution: 2592 x 1944 , 5.0 Megapixels
• Minimum illumination:0. Lux/F1.2(0Lux IR ON)
• IR Distance: 15-30M
• IR Cut function, Day@night Surveillance
• Non coding compression, High Efficiency, without delay real-time transmission
• Up to 500 meters lossless transmission with 75-3 coax
Specification:
| Model | BA-WK4250EA-B |
| Camera | |
| Image Sensor | 1/2.5" 5.0 Megapixel CMOS |
| Solution | NVP2475+K03 |
| Effective Pixels | 2560(H)x1944(V) |
| Electronic Shutter | 1/50s ~ 1/60,000s |
| Video System | PAL/ NTSC |
| Video Frame Rate | AHD 20 fps@2560×1944P |
| Video Output | 1CH, AHD |
| Smart IR control | Support |
| Min. Illumination | [email protected](AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W) |
| White Balance | Auto |
| Other | AWB,AGC,BLC |
| IR Led | |
| IR Led | ¢5X42PCS |
| IR Distance | 15-30M |
| Lens | |
| Focal length | Fixed lens 3.6/6mm |
| General | |
| Power Supply | 12 VDC ± 10% |
| Power Consumption | < 5 W |
| Operating Temp. | -30ºC-(+60)ºC, 10%-90%RH |
| Transmission Distance | Over 300m via 75-3 coaxial cable |
