Fsan Outdoor 2.0/3.0MP IR Dome Humanoid Capture Detection IP Camera
FSAN Outdoor 2.0/3.0MP IR Dome Humanoid Capture Detection IP Camera Product DescriptionResolution 3mp (2304x1296@25fps)Built-in Humanoid Detection algorithm;Detection frame 5fps, detect 5 people at the same time;Low consumption, low code stream, low delay;H.265 compression format, save bandwidth and......
Send Inquiry
Product Description
- Resolution 3mp (2304x1296@25fps)
- Built-in Humanoid Detection algorithm;
- Detection frame 5fps, detect 5 people at the same time;
- Low consumption, low code stream, low delay;
- H.265 compression format, save bandwidth and storage space;
- Support Smart IR to avoid Infrared over-exposure at night;
- Support ICR auto switch, achieve best result for D&N video;
- Support PoE power supply(optional)
- With SD/TF card slot for local storage
- Support smart auto startup SD/TF card record offline
- Support alarm, reset, RS485
- Support auto-electronic shuttle to suit different surveillance environment
- Support two-way audio intercom
- Support HTTPS encrypted transmission
- Support On-vif, email, NTP service
- Change the password during initial use to ensure the security of the password
Camera | |
DSP | T31N |
Sensor | Color 1/2.9" Low Illumination CMOS Sensor GC2063 |
Lens | 2.8mm IR lens |
IR Distance | 20m(18pcs*IR leds) |
D&N | ICR Switch, Auto/Color/B&W/CDS Trigger |
D-WDR | D-WDR (off/low/middle/high) |
IR Led Control | Auto/Manual/Off |
3D DNR | Off/Low/Middle/High/Higher |
Defog | Off/Low/Middle/High |
Mirror | Off/ Horizontal Mirror/Vertical Mirror/180-degree flip |
Image Setting | Brightness, Contrast, Sharpness, Saturation, Chroma |
Humanoid Detection | |
Detection Quantity | ≤5 people humanoid targets |
Humanoid Size | Humanoid Pixel ≥ 40*40, range 30-30 |
Detection Ratio | ≥99% (meet above requirement) |
Capture Corresponding Speed | ≤1s |
Max Detection Frame | 5fps/s |
Fault Detection Ratio | ≤2% |
Detection Part | People with any posture including half body, head, hand, shoulder |
Track People | Support |
Detection Mode | Support static and dynamic humanoid detection |
Detection method | Image detection during day time or night time with lights or IR LEDs |
Detection Area | Appointed area, default full-screen |
Upload Method | Upload it under private protocol |
Trigger Method | Video trigger |
Audio & Video Encoding | |
Video compressing | H.265/H.264 |
| H.265 Encoding | / |
h.264 Encoding | BaseLine / Main Profile / High Profile |
Encoding Feature | Main stream: 2MP 1920x1080@25fps Sub-stream: D1(720*576), VGA (640*360) |
Max resolution | 3MP 2048x1536@25fps |
Video Code Rate | Fixed code rate, variable code rate (Main stream: 160Kbps-4000kbps) |
Video Type | Composited stream/video stream |
Audio Standard | G.711u / 64Kbps |
Network Function | |
Network Protocol | TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP |
Access Protocol | ON-VIF, GB28181 (Option) |
Security Mode | Authorized user name and password, HTTPS encryption, AES connecting encryption, RTSP verification |
Motion Detection | Set detection area, can set multi-level sensitivity |
Privacy Mask Alarm | Support 1 area |
Privacy Mask | Support 4 areas |
Schedule Linkage | Snapshot, email |
Device abnormal Inspection | Support network broken alarm, IP conflict alarm, illegal visiting alarm |
Character Overlay (OSD) | Title, time and date overlay, multi-line, and color of characters optional |
DST | Support |
| Snapshot | Support linkage capture |
| System update | Support for Web-side upgrades |
Port | |
Network Port | RJ45 10M/100M network self-adaptation |
Audio | MIC Input/ Output |
RS485 | Support |
| Alarm | Support |
| Reset | Support |
| SD/TF card slot | Support |
General | |
Power Supply | DC12V /PoE (optional) |
Working Temperature | -10°C ~ 50°C |
Working Humidity | 0%~90% |
