Gscam 1080P WiFi Camera for Home Security
2MP Shaking Machine (T20L+SC2235) SpecificationMaster ControlT20LImage SensorSC2235 2MP, starlight levelPixel Array1920*1080Fit Lens3.6mm focal length wide-angle lensTypical power consumption (mW)1500Working conditions / storage conditions -10ºC~+50ºC@humidity10%~ 95%non-condensing......
Send Inquiry
Product Description
| 2MP Shaking Machine (T20L+SC2235) Specification | |
| Master Control | T20L |
| Image Sensor | SC2235 2MP, starlight level |
| Pixel Array | 1920*1080 |
| Fit Lens | 3.6mm focal length wide-angle lens |
| Typical power consumption (mW) | 1500 |
| Working conditions / storage conditions | -10ºC~+50ºC@humidity10%~ 95%non-condensing / -40ºC~+75ºC@humidity10%~ 95%non-condensing |
| Audio and Video Function Parameters | |
| video coding | Smart H.264 ultra low bit stream |
| Typical video stream (Kbps) | 512(peak value) |
| Typical video frame rate (FPS) | 25(Daytime)/12( Nighttime) |
| Audio sampling rate | 8K |
| Audio coding | G.711 coding |
| Audio mode | Bi-directional single pass |
| Audio and video encryption | "video cloud" PDES cloud encryption, support system key and custom key two modes. |
| Audio and video transmission | "video cloud" cloud forwarding (non P2P), services cover the whole world. |
| Audio and video local storage | Support MicroSD card storage, 8G-128G, continuous storage / scheduled storage |
| Audio and video cloud storage | "Video Cloud" cloud storage, service coverage of the world, optional 7 days / 30 days event storage,7 days / 30 days continuous storage. |
| Voice Announcements | Support Chinese, English, Japanese and Portuguese |
| Message push | "video cloud" SNS push, service covers the whole world |
| Interface Function Parameters | |
| Power interface | Micro-USB socket, DC 5V power supply. |
| Indicator light | Onboard, red and green bicolor lights |
| MicroSD Card slot | Onboard support 8G-128G capacity MicroSD card |
| Reset button | Onboard, vertical or horizontal keys are optional, hold and hold 1S, remove camera binding and clear configuration. |
| WiFi module | On board RTL8188FTV |
| WiFi antenna | Built in sticker antenna |
| Ethernet | On board RJ45 socket |
| Microphone | Support (-32~-36) DBM all directional electret microphone. |
| speaker | Support external 8 1W speaker |
| Day and night control | Detection of external photosensitive tube |
| Infrared lighting | Support 850nm/940nm infrared LED |
| motor drive | Support dual gear stepper motor |
| Network Function Parameters | |
| WIFI | IEEE802.11b/g/n |
| Frequency Range | 2.4GHz~2.4835 GHz |
