China Support Pppoe Aluminum Alloy Housing Long IR Distance IP Camera

Product Description

Support PPPOE Aluminum alloy Housing Long IR Distance IP Camera

Features

1/2.8"SONY Exmor Sensor Progressive Scan;

Auto Iris, Auto electronic shutter, adapt to different environment;

Support Static IP(IP address, Subnet Mask, Gate way and DNS can be set);

Support PPPOE, RSTP, VLC, NTP, UPNP;

Support triple streaming simultaneous output, 1x1080p(network transmission)
With 2xD1(storage and mobile browsing), max frame rate 25fps

Bit-rate switchable(VBR and CBR);

3D DNR, D-WDR, Antifog, Antistemble;

5 user IE viewing in the same time; 4 mask zone;

4ch multiscren play back in the same time

Our Service:

(1) Prompt reply: Your inquiry related to our products or price will be replied within 24 hours.
(2) OEM Service: We offer customized options for our products, and customer's designed LOGO printing is available.
(3) Quality Control: All products we sold are 100% strictly selected and tested by our QC department.
(4) Warranty: We offer 2 years product warranty.

Our Advantages

High quality products
Full selection range
Two years warranty/free maintainance
OEM & ODM Service
CE, FCC, RoHs Certified
Payment: T/T, Paypal, Western Union D/P L/C
3-5 daysprompt delivery
Welcome sample order for testing
Excellent after-sales services
Experienced sales team

Our Service:
1) We'll Gurantee you 100% Satisfaction
2) Pls report us if there are any problem, we will solve it ASSP.
3) This irems comes with 2 Years warrantry
4)Shipping and handing fees are not refundable for return
5) Should you have any question or problems, please send e-mail, call us or talk with us online

Specification
Model		WS-IP316
Hardware
SOC		Hi3516C
Image Sensor		1/2.8" 2.1 Megapixel progressive scan Sony EXMOR CMOS 122
Effective Pixels		1920(H) x 1080(V)
Interface
Optical Lens	Interfaces	CS
	Iris	Fix Iris
	Focal Length	6mm
Audio Talkback		1ch MIC External access, 3.5mm AV interace(Optional)
Audio Output		1ch speaker output, 3.5mm AV interface(Optional)
Network Interface	Lan	10/100M BASE-TX, RJ-45 connector
RS 485		RS485 Port Optional
Alarm I/O		1ch Alarm input or 1ch alarm output(Optional)
Memory Slot		Optional
Audio & Video encoding
Video Compression		H.264 Main Profile; MJPEG Baseline
Resolution	Main steam	1920x1080/1280x720;1-25fps(Adjust)
	Sub steam	720x576/640x480/640x352/352x288/320x240;1-25fps(Adjust)
Video Bitrate		30Kbps - 16Mbps, Support CBR/VBR
Tilt OSD Setting		Supports channel name, date, and video stream information overlay
Privacy Mask		4 configurable regions
Image Orientation		image flip and mirror
Auto Image Control Function		Auto Exposure Control(AEC);Auto white Blance(AWB);Auto Gain Control(AGC)
Mnaual Image Controls		Color saturation, hue, gamma, sharpness(edge enhancement)
Others		Anti Fogging/Anti Trembliing/IR Detection/IRIS
Audio Compression		G.711A/G.711U/G7.26
Two Way Audio		Support
Date transmission and storage
Date Storage		Video and Image
Recording		Recording set up to record by Auto or manual(motion and alarm trigger, schedule)
Alarm Output		FTP,E-mail
Network protocol		TCP/IP,UDP,RTP,RTSP,RTCP, HTTP,DNS,DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNP
Wireless Protocol(-W)		``````````````
ONVIF protocols		Support 2.2 Version
Remote View	PC	IE 6.0 above; Firefox; Google Chrome
	Mobile Phone	Support Windows Mobile, Symbian, iPhone, Android system
	Max. User Access	5 Users
General Parameters
Environmental Casing		Aluminum alloy Housing, Outdoor Use
Installation		Ceiling/Wall Mount, 3D adjustable
Operating Temperature		-10°C - +50°C
Operating Humidity		0%-85% RH
Power		DC12V
POE		``````````````````
Power Consumption		<9W
Dimension		L340xW108MM
Weight		830g
