Video Balun 1-#9198
1. Full-motion CCTV video at distances up to 450-650m when used with any passive transceiver 2. Up to 1500m with any active UTP video receiver3. Tool-less, installs in seconds, no need to strip the wires4. NTSC, PAL, and SECAM video formats5. No power required6. 60dB crosstalk and noise immunity7. C......
Send Inquiry
Product Description
1. Full-motion CCTV video at distances up to 450-650m when used with any passive transceiver
2. Up to 1500m with any active UTP video receiver
3. Tool-less, installs in seconds, no need to strip the wires
4. NTSC, PAL, and SECAM video formats
5. No power required
6. 60dB crosstalk and noise immunity
7. Compact size easy installation
8. Frequency Response: DC to 8MHz
9. Attenuation: 0.5dB type
10. CMRR: 60dB
11. Impedance: BNC: 75 Ohms
Terminal: 100 Ohms
12. Working temperature: -10 to + 70°C
13. Storage temperature: -30 to +70°C 1
14. Humidity: 0 to 95%
15. Dimensions: 180*17*15mm
UTP balun features:
1.BNC-M connector, screw push terminal wire, wired more stable reliable
2. No power required, simplified project wiring
3. Plug and play, real-time transmit CCTV video signal, video is clear and stable
4. Anti-interference, super lighting protection, ESD
5.Effective distance: 450-650m (passive)
6.100 pairs a box size: 38x20x20cm
Anted electronics works with super quality, satisfactory services
All the products from Anted electronics are tested by our QC before being stocked, and most of the hot products are in stock, making it possible to ship within 48 hours for sample, bulk order based on the quantity
Electronics below wholesale
Anted electronics offers you competitive wholesale/drop ship prices Anted electronics will be the best choice for customers who has his own business
Preferential price is also provided to our regular customers
No minimum quantity request! The more quantities you order, the more discounts you will get
Payment:
We accept PayPal, western union and bank transfer (T/T)
12 months warranty:
All products from Anted electronics are provided with 1 year warranty
Refund, return or repair are accepted according to different conditions
OEM, ODM accepted
Fast delivery:
DHL, FedEx, UPS, TNT, EMS and Air Mail are available
Most of orders will be sent out within 2 business days
Before sending, all packing will be checked again to ensure their perfectibility
Usually, the lead-time is 3-5 days to the major worldwide countries
| Characteristic impedance | 75 Ohms | |
| Frequency range | 4GHz DC | |
| VSWR | ≤1.30 at DC 1000MHz | |
| Insertion loss | ≤0.2dB | |
| Working voltage | 500V RMS, 50Hz, at sea level | |
| Dielectric withstanding voltage | ≥1500V RMS, 50Hz, at sea level | |
| Dielectric resistance | ≥5000MΩ | |
| Contact Resistance | Center contact ≤1.5mΩ | Outer contact ≤1.0mΩ |
| Durability | Mating cycles ≥500 | |
| Parts name | Material | Plating |
| Body | Brass | Ni |
| Insulator | PTFE | - |
| Inner conductor | Phosphor bronze | Au |
| Coupling nut | Brass | Ni |
| Gasket | Silicone rubber | - |
| Ferrule | Annealed copper | Ni |
| Operating temperature | _45 to 85°C | |
| Weatherproof rate | IP67 | |
| RoHS Directive-compliant (2002/95/EC) | Compliant by exemption | |
| Suitable cable family | RG59 cable | |
