Product Description

Product feature()

4K Super HD
Support 4K ultra high definition, ultra high definition with ultra high resolution, the maximum can provide 4K@30fps/ 25FPS image coding output, at the same time backward compatible with 1080p, 720p resolution.
USB 3.0
Full function USB 3.0 interface, power supply, video, audio IN one, can also support 1 USB+1 HDMI, built-in MIC(LINE IN)
Lens
The horizontal wide-angle field of view is up to 110° and the vertical wide-angle field is up to 76°. It also supports remote control EPTZ to keep the brakes on, which makes it bigger and clearer to see.
Dual array built-in microphone
Dual array built-in microphone, omnidirectional pickup, pickup distance up to 6 meters, unique intelligent noise reduction algorithm, so that your speech perfect presentation.
WDR
Support digital WDR, easy to deal with different lighting environment, no matter how harsh the environment can restore the most real you.
Low Lux
The new starlight ultra-high noise ratio CMOS image sensor can effectively reduce the image noise in the case of low illumination. At the same time, 2D and 3D noise reduction algorithms are applied to reduce the image noise significantly. Even in the case of ultra-low illumination, the picture is still clean and clear, and the image SNR is up to 55dB.
Easy to install
The standard rotating shaft support with damping is suitable for almost all displays on the market, with simple installation, stability and reliability.
1/2.8" 8M image sensor;
Use ARM 4*[email protected] + 1*Cortex[email protected] CPU architecture SOC
Built-in CEVA 4*XM4@1GHz DSP, integrated 4K ISP, support 4K-HDR;
Support image MJPG, YUY2, H.264, H.265 encoding output;
UVC architecture, compatible with Windows 8&10,LINUX,Andriod,MAC OS;

2. SPECIFICATIONS()
1) Common()

Signal	CMOS	REMARKS
Image Sensor()	1/2.8 " CMOS	Sony
Effective Pixels()	8.42Millions of Pixels
Pixel size()	1.45um*1.45um
Video output()	YUV/MJPG/H264
Maximum Frame Rate ()	YUY2 *@19201080*@30FPS(default) YUY2 @1280720@30FPS YUY2 @ 800* 600@30FPS YUY2 @ 640* 480@30FPS	@USB3.0
Maximum Frame Rate ()	MJPG&H264 @19201080@30FPS(default) MJPG&H264* @3840*2160@30FPS MJPG&H264 @25921944@30FPS MJPG&H264 @25601440@30FPS MJPG&H264 @20481536@30FPS MJPG&H264 @16001200@30FPS MJPG&H264 @1280*720@30FPS	@USB3.0
Maximum Frame Rate()	3840*2160@30FPS	@H.264
Maximum Frame Rate()	3840*2160@30FPS	@HDMI
SNR max()	55dB
Dynamic range()	72dB
Hardware Interface()	USB3.0 ,HDMI
Interface rate()	5Gb/S
Power requirements()	5V±5%
Power Consumption ()	5W Max
Dimensions(PCBA)mm	120x36 ±5%
Weight()	TBD
Operating temperature(ºC)()	-20ºC ~ +55ºC
Storage temperature(ºC)(&)	-40~80 ºC/0~90RH
Compliance()	USB-IF WHQL CE RoHS
Lens Fit()	M12(f=1.9MM)
Lens view ()	M12
Warranty()	3 years
OS()	Windows 8/10,Mac,linux,Android(Standard UVC)
