Good Quality Ahd DVR with CCTV Camera
Promotion price of AHD DVRSpecification* Support TVI 2.0 1080P and AHD 720p/Analog input;* 4 in 1: support TVI 2.0, AHD 1.0, CVBS, IPCAM;* 10 formats can be matched freely, no limitation of PAL&NTSC: TVI (720P@25/30/50/60fps,1080P@25/30fps), AHD (720P@25/30fps)CVBS(960H@PAL/NTSC);* Support 6......
Send Inquiry
Product Description
Promotion price of AHD DVR
Specification
* Support TVI 2.0 1080P and AHD 720p/Analog input;
* 4 in 1: support TVI 2.0, AHD 1.0, CVBS, IPCAM;
* 10 formats can be matched freely, no limitation of PAL&NTSC: TVI (720P@25/30/50/60fps,1080P@25/30fps), AHD (720P@25/30fps)CVBS(960H@PAL/NTSC);
* Support 600m BNC video output;
* Support 1080P-H encoding, 1080P video just take 720P's storage;
* Remote view:Support free P2P, Android/iOS/PC.
* Quick connect with the ESEECLOUD,fluent and stable video on preview and playback;
* Dual stream function achieve local HD record and fluent internet transmit of the same video;
* Multiple software upgrade mode;
* Free P2P,support Android/IOS(Esee cloud),PC remote and free CMS.
.
Specification
* Support TVI 2.0 1080P and AHD 720p/Analog input;
* 4 in 1: support TVI 2.0, AHD 1.0, CVBS, IPCAM;
* 10 formats can be matched freely, no limitation of PAL&NTSC: TVI (720P@25/30/50/60fps,1080P@25/30fps), AHD (720P@25/30fps)CVBS(960H@PAL/NTSC);
* Support 600m BNC video output;
* Support 1080P-H encoding, 1080P video just take 720P's storage;
* Remote view:Support free P2P, Android/iOS/PC.
* Quick connect with the ESEECLOUD,fluent and stable video on preview and playback;
* Dual stream function achieve local HD record and fluent internet transmit of the same video;
* Multiple software upgrade mode;
* Free P2P,support Android/IOS(Esee cloud),PC remote and free CMS.
| Item | Model | HVR5104 | HVR5108 | HVR5116 |
| System | Main Chipset | Hi352DV200 | Hi3521 | Hi3531 |
| Operating System | Embedded LINUX Operating System | |||
| Video Specification | Video Input | 4CH | 8CH | 16CH |
| Preview Resolution | TVI1080P-H@25fps /AHD720P@25fps / 960H/@25fps / IPC1080P@25fps | |||
| Video Compression | H.264 | |||
| Encoding Resolution | 1080P-H(960*1080)/720P/960H/D1 | |||
| Frame Rate | TVI/ AHD/Analog@15FPS, IPC @25fps | |||
| Video Coding rate | 512Kbps~4096Kbps | |||
| Video Playback | 4ch *1080P-H(960*1080)/720P/960H/D1 | |||
| Dual Stream | support | |||
| Audio specification | Audio Compression | G.711A | ||
| Audio Rate | 8KHz/16Bit | |||
| Video Interface | Video Input | BNC Interface x 4 | BNC Interface x 8 | BNC Interface x 16 |
| Video Output | 1 ch VGA output,1 ch HDMI output | |||
| Audio Interface | Audio Input | 4CH | 4CH | 1CH |
| Audio Output | 1 RCA Audio Output/HDMI Audio Output | |||
| Alarm | Alarm Input | 4ch (optional) | ||
| Alarm Output | 1ch (optional) | |||
| HDD | Interface Type | 1-2 SATA | 1-2 SATA | 2-4 SATA |
| Single capacity | MAX 4TB | |||
| External Interface | Network Interface | 1 RJ45 Interface, 100M Ethernet Interface | ||
| Serial Interface | 1 RS485 | |||
| USB 2.0 | 2 | |||
| Other Information | Power Supply | DC12V | ||
| Working Temperature | -10~55 | |||
| Working Humidity | 10%~90% | |||
.
